Simplex 562-817 Status Command Center (SCU), Board PC
The 562-817 is the PC board for the Simplex 4602 Series Status Command Unit (SCU), a remote LED annunciator with 16 red zone status LEDs. The SCU connects to the fire alarm control panel over supervised RUI communications, and several units can be mounted together for more zones.
Key Features
- 16 red zone status LEDs
- LEDs are pluggable for color change or replacement
- On-board pushbutton for LED test
- Supervised RUI communications over one twisted, shielded pair; power on a second pair
- Terminal block connections
Specifications
| Voltage |
18.9 to 32 VDC from the fire alarm control panel |
| Current (4602-9101 SCU) |
Supervisory 36 mA; alarm 55 mA |
| Communications |
RUI (Remote Unit Interface) |
Compatible With
- Simplex 4005, 4007ES, 4010ES, 4100ES and 4100U
- Simplex legacy 4002, 4020, 4100, 4120 and Universal Transponders (UT)
