Simplex 4100-2126 is the red glass door and dress panel for a three-bay 4100ES box, the door-only part used when box and door ship separately. Simplex specifies glass doors with modular dress panels where annunciation and interface modules must stay visible: fire alarm control units, network display units and remote annunciators.
Specifications
| Description |
Glass door and dress panel, 3 bay |
| Color |
Red |
| Matching box |
2975-9409, 3-bay red box (ordered separately) |
| Enclosure rating |
NEMA 1; wall mount enclosures also IP30 |
| Dress panels |
Latching, lift off for internal access |
Compatibility and installation notes
- Order the 2975-9409 red 3-bay box separately, or order the combined box with glass door and dress panel, 2975-9443, if both ship together.
- Door keys ship with the system master controller; 252-019 is the replacement B key.
- For the door to open 180 degrees, the exposed cabinet dimension from the wall must be at least 3 in. (76 mm).
- Installation instructions 579-117.
Related models
- 4100-2124 and 4100-2125: red glass door and dress panel for 1-bay and 2-bay boxes
- 4100-2104, 4100-2105, 4100-2106: platinum glass doors for 1, 2 and 3 bays
- 4100-2136: red solid door for a 3-bay box
-
2975-9443: red 3-bay box with glass door and dress panel, shipped together
Documents
Specifications from Simplex data sheet S4100-0037 Rev. 17, 5/2021, Cabinet Reference; Boxes, Doors, Dress Panels, Rack Mounting, and Accessories. Manufacturer specifications are subject to change.
