Notifier JSKM-CMM-9G — addressable input/output module from the Notifier 9G family, for the China-market NFS3-3030 system.
One module covers both directions of a single interface point. The input channel monitors a voltage-free normally open contact — a flow switch, a damper or fan status contact — and reports its state. The output channel gives a supervised 24 VDC output and monitors both the output wiring and the external supply feeding it. It ships set for dual addressing; shorting T6 to T7 leaves only the output address, T3 to T4 only the input address.
- 15–32 VDC; standby 350 µA @ 24 VDC, no comms
- External supply input 24 VDC nominal, 2 A maximum
- Output capacity 2 A @ 30 VDC; 0.5 A @ 125 VAC resistive
- 124.6 × 124.6 × 57.5 mm with back box and faceplate; 170 g
- –10° C to 55° C, 5% to 95% RH
- Built to GB 16806-2006, UL 864 and FM 3010
This is a China-market catalogue number. It appears nowhere in the North American Notifier SLC wiring manual, so do not order it as a substitute for an FCM or FMM series module on a US NFS panel. Within the 9G family, JKM-FCM-9G is output only, JSM-FMM-9G input only and ISO-9G the isolator.
