VESDA E700-SP-DCL-PNT — round sampling point label for VESDA aspirating pipe networks, supplied on a roll of 50.
An aspirating system draws air through small holes in the sampling pipe, and those holes are invisible once the pipe is up. These labels mark each sampling position so a later ceiling change, inspection or repaint does not block or lose it. This is the round style, with a hole in the centre, which fits around a miniature sampling point instead of wrapping around the pipe.
- Round label with a centre hole, sized to fit the E700-SP miniature sampling point
- Supplied 50 per roll
- Part of the VESDA pipes and fittings range for 3/4 in. CPVC pipe
- Marking accessory only: no electronics and no detection function
- Current in the June 2024 VESDA Pipes and Fittings ordering list
Three VESDA labels are easy to confuse. E700-SP-DCL is the wrap-around sampling point decal at 200 per roll, aligned over a hole drilled in the pipe; E700-SP-DCL-PIPE is the pipe label at 35 per roll, warning against tampering rather than marking a hole; E700-SPLR and E700-SPLG are the red and grey sheet labels.
