Napco FLX2-32 — FireLink conventional fire alarm control panel with eight onboard zones, expandable to 32 points, and a StarLink Fire MAX2 dual SIM cellular communicator built in.
The panel ships preprogrammed: zone one waterflow, zone two supervisory tamper, zone eight communicator trouble. The integrated communicator replaces two POTS lines, picking between two carrier networks on quality of service. Expansion is not limited to conventional devices: the board also takes one addressable SLC loop.
- Eight conventional zones for two-wire detection, expandable to 32 zones or points
- One addressable SLC loop on the main board, supporting a single 32-point loop
- Two onboard NAC circuits at 2 A each, programmable to four, 4 A total at 24 V
- 4 A at 24 V supply; up to 96 outputs; one NAC selectable at 12 V
- Built-in backlit LCD annunciator; holds up to 16 Ah of standby battery
- UL 864 10th Edition and UL 985 listed
This is the conventional member of the FireLink family, not the FLX2-255, which is a 255-point addressable panel. Annunciators are ordered separately as FL-FK1 or FLX-RFA.
