Honeywell 5150-0002 — replacement keypad membrane for the Gamewell-FCI 7100 Series fire alarm control panel, supplied as a service part.
The 7100 Series is the compact analog addressable fire alarm control panel from Gamewell-FCI, a Honeywell brand. Its base system module carries the 80-character LCD display and the programming keypad, and this membrane is the printed switch overlay on that keypad. Gamewell-FCI documents the keypad as a 12-button pad together with Alarm Acknowledge, Trouble Acknowledge, Signal Silence and System Reset/Lamp Test switches and Menu/Back, Back Space/Edit and OK programming buttons. Keypad functions are enabled only when the keylock is turned to the unlocked position, the one exception being Trouble Acknowledge, and the PK-625 key switch is keyed alike with the door lock — which is why the membrane is catalogued for 7100 keypads both with and without lock.
Gamewell-FCI publishes no data sheet for 5150-0002, so we quote no dimensions or material for the part, only the panel it serves. Verify the number against the equipment: the adjacent 5150-0003 is listed for the LCD-7100 annunciator keypad.
