Gentex GESB24PWW is a strobe-only appliance with a blue lens and selectable candela, from the Gentex Commander3 colored lens series. It is a wall-mount, low-profile 24V DC strobe for emergency communication, severe weather warning and similar visual notification needs.
The series ships with a standard 4-inch mounting plate that has the Super-Slide feature for supervision testing, and a locking mechanism that holds the signal on the bracket without visible screws. The Checkmate feature lets the installer check voltage drop at the device against the plans.
Features
- Blue lens, strobe only
- Tamperproof field-selectable candela: 15, 30, 60, 75 and 110
- Nominal 24V DC
- Super-Slide bracket for easy supervision testing
- Checkmate instant voltage verification
- Can be synchronized with a Gentex AVSM control module
- Prewire the system, mount the bracket, then install the signals
- Input terminals accept 12 to 18 AWG
Specifications
| Lens color |
Blue |
| Housing color |
White |
| Input voltage |
24V DC |
| Candela options |
15, 30, 60, 75, 110 |
| Dimensions (H x W x D) |
5 x 4.5 x 2.5 in. (12.7 x 11.43 x 6.35 cm) |
| Mounting |
Wall mount, surface or box mount |
