Gentex GECG24PWW (904-1332-002) is a wall-mount horn/strobe from the Commander3 colored lens series, with a green lens and a white faceplate. Strobe candela is field selectable, and the unit has no lettering.
The horn offers a continuous or synchable temporal 3 tone at 2400 Hz, a mechanical tone, a chime and a whoop tone, all changed in the field with switches. The device ships with a standard 4 in. mounting plate with the Super-Slide feature, which lets the installer test for supervision, and a locking mechanism hides the mounting screws.
Features
- Green lens with white faceplate; plain, no lettering
- Tamper-proof, field-selectable candela: 15, 30, 60, 75 and 110
- Selectable tones including temporal 3 (continuous or synchable), mechanical, chime and whoop
- Super-Slide mounting plate for supervision testing
- Checkmate feature for instant voltage verification of voltage drop
- Listed to ANSI/UL 1638 and ANSI/UL 464 and/or CAN/ULC S525 and S526; series meets ANSI/UL 1971 rated candela
- 3-year warranty
Specifications
| Type |
Horn/strobe, wall mount |
| Lens color |
Green |
| Faceplate |
White |
| Candela settings |
15, 30, 60, 75, 110 |
| Height |
5 in. |
| Width |
4.5 in. |
| Depth |
2.5 in. |
