Gamewell-FCI MMI-10F — a Velociti® Series Multi-Mod ten input monitor module that provides ten Style B (Class B) or five Style D (Class A) supervised initiating device circuits on a Gamewell-FCI analog addressable signaling line circuit.
Each supervised circuit may be connected to any normally open contact device such as manual stations, tamper and supervisory switches, waterflow switches, heat detectors and 4-wire smoke sensors. Every circuit occupies its own SLC address, so each is fully programmable in its own control-by-event sequence of operation. The address of the first circuit is set with a pair of rotary dials and the remaining circuits are automatically assigned to subsequent addresses; an address disable jumper matrix lets a maximum of two unused addresses be turned off to free them for other purposes, and an additional jumper selects Style B or Style D circuit configuration. Each circuit has its own status LED that flashes to indicate proper polling and lights steadily when the output has been activated. The module is intended for applications where centralized location of circuits is required — as many as sixty initiating device circuits fit in a single 12.6 in. H x 24 in. W x 6.5 in. D cabinet.
Specifications
| Type |
Velociti® Series ten input monitor module (Multi-Mod) |
| Circuits |
Ten Style B (Class B) or five Style D (Class A) supervised IDCs, individually addressable and programmable |
| Operating voltage |
15–32 VDC |
| Stand-by current |
3.5 mA |
| Alarm current |
60 mA (with all ten LEDs lit) |
| Maximum IDC wire resistance |
40 Ohms |
| Maximum IDC voltage |
12 VDC |
| Maximum IDC current |
1 mA |
| Temperature range |
32°F to 120°F (0° to 49°C) |
| Humidity |
10 to 85% (non-condensing) |
| Module dimensions |
6.8 in. H x 5.8 in. W x 1.25 in. D (17.3 x 14.7 x 3.2 cm) |
| MBB-2 backbox |
12.25 in. H x 9.25 in. W x 3.32 in. D (31.2 x 23.5 x 8.4 cm) |
| MBB-6 backbox |
12.63 in. H x 24 in. W x 6.5 in. D (32.1 x 60.1 x 16.5 cm) |
| Field wiring |
Removable terminal blocks, 12 to 18 AWG |
| Standards |
UL 864 9th Edition; UL 2572 for Mass Notification |
| UL |
S1913 |
| FM |
3023594 |
| MEA FDNY |
219-02-E Vol VI |
| CSFM |
7300-1703:0124 |
Installation notes
-
Address block, not a single point: the first circuit address is set on the rotary dials and the module then consumes the following consecutive addresses on the SLC. Plan the address map so the block does not collide with other devices.
-
Freeing addresses: the jumper matrix can disable a maximum of two unused circuit addresses.
-
Style selection is module-wide: a single jumper setting selects Style B or Style D — in Style D the ten circuits become five Class A circuits.
-
LED behavior depends on the panel: the bi-color LEDs flash green when the device is addressed and light steady red on alarm, but only the red LED is operative in panels that do not operate in Velociti® mode.
-
Mounting: two Multi-Mod units fit one MBB-2 cabinet. The MCH-6 six-unit chassis mounts in the MBB-6 cabinet or in a custom cabinet for up to six modules.
-
Recommended environment: although the system meets NFPA requirements over 32–120°F, Gamewell-FCI recommends installation at a normal room temperature of 60–80°F (15–27°C) to protect the useful life of electronic components.
Related models
-
MBB-2 — two-unit backbox for Multi-Mod modules.
-
MBB-6 — six-unit backbox; requires the MCH-6 chassis.
-
MCH-6 — six-unit mounting chassis for a custom cabinet or the MBB-6.
Specifications taken from the Gamewell-FCI data sheet “Velociti® Series MMI-10F Multi-Mod Ten Input Monitor Module,” document 9020-0631 rev. D (11/17). Manufacturer specifications are subject to change without notice.
