The Gamewell-FCI GWMS95-DL is a dual-action addressable manual pull station that uses the XP95 (Apollo) protocol. It is made for Gamewell-FCI systems built on XP95 signaling line circuits, where each pull station reports its own address to the panel. Because two separate motions are needed to start an alarm, the dual-action design helps prevent accidental activations in busy corridors and public areas.
Key Features
- XP95 (Apollo) protocol addressable interface
- Dual action: push in, then pull down the handle
- Key reset
- Red Lexan (or equivalent polycarbonate) housing with textured finish
- Address set in the field at the station
Specifications
-
Manufacturer: Gamewell-FCI
-
Part Number: GWMS95-DL
-
Type: Dual-action addressable manual pull station
-
Protocol: XP95 (Apollo)
-
Loop Capacity: Up to 126 stations per XP95 loop
-
Mounting: Semi-flush to a single-gang, double-gang or 4" square electrical box; surface mount with the SB-I/O backbox (sold separately)
Compatibility
Designed for Gamewell-FCI 600 Series fire alarm control panels that use XP95 addressable SLC loops.
