Gamewell-FCI 1100-0654 — BC-1R battery cabinet, red, for sealed lead calcium standby batteries too large to fit inside the control panel.
When a Gamewell-FCI system needs extended standby, the batteries move out of the panel and into a separate enclosure. The BC-1 cabinet is built from 16 gauge steel, phosphate treated and primed with zinc chromate before painting, with knockouts at each end and a hinged, locking cover keyed alike with Gamewell-FCI control panels so one key serves the whole installation. Part number 1100-0654 is the red finish, matching the various Gamewell-FCI control panels.
- Houses up to four B-31 (31 AH) batteries, or two B-55 (55 AH) batteries
- Cabinet dimensions 22" L × 10" H × 8.81" W (55.88 × 25.4 × 23.38 cm)
- 16 gauge steel, UL Listed, hinged locked cover keyed alike with Gamewell-FCI panels
- Batteries are ordered separately: B-31 is 100-2610A, B-55 is 100-2710A
Order by finish and by battery size. 1100-0653 is the same BC-1 cabinet in beige, and the smaller B-1.9R, B-7R and B-17R cells are normally panel-mounted, so a BC-1R bought to hold them is usually the wrong call.
