Fire-Lite CRF-300-6 is a six-relay addressable control module with six Form-C relays. The control panel switches each set of dry contacts on command, and each contact can be wired normally open or normally closed.
The first module is addressed from 01 to 154, and the other five relays take the next five higher addresses automatically. Up to three unused addresses can be disabled. No supervision is provided for the controlled circuit.
Features
- Six addressable Form-C relay contacts, one isolated dry contact set per address
- Removable plug-in terminal blocks
- Panel-controlled green LED per point that can blink, latch on or latch off
- Rotary address switches; unused addresses may be disabled
- Mounts one or two modules in an optional BB-X2F cabinet
- Mounts up to six modules on an optional CHS-6 chassis in a BB-2F cabinet
Specifications
| Product Type |
Relay module |
| Relays |
6 x Form-C |
| Height |
6.8" |
| Width |
5.8" |
| Depth |
1" |
