Fiplex by Honeywell HONBDA-D-7S33A-R is the DC-powered remote unit of the FLEX Series small public safety centric fiber DAS for 758 to 869 MHz (PS700, FirstNet and PS800, dual band). Honeywell describes the small DAS as one Master-Remote unit and two Remote units linked over single-mode fiber; the remote re-radiates the downlink at +33 dBm per band. It is ordered with a matching master, not on its own.
Specifications
| Bands |
PS700, FirstNet, PS800; 758 to 869 MHz |
| Downlink composite output |
+33 dBm per band |
| Channel filters |
32 channels plus 2 bandwidth-adjustable per band; 12.5 kHz to 150 kHz filter bandwidths |
| Optical ports |
1; single-mode fiber with WDM, 1310/1550 nm |
| Supported fiber loss |
20 dBo maximum |
| Optical connectors |
LC/APC, compatible with LC/UPC |
| Uplink |
0 dBm maximum input; squelch per channel, programmable |
| Manual attenuator |
20 dB in 1 dB steps |
| RF connectors |
N female, 50 Ω |
| Overall gain (master + remote) |
85 dB regardless of fiber length; noise figure below 9 dB |
| Power consumption |
80 W |
| Housing |
NEMA 4 |
| Temperature / humidity |
-22 °F to +131 °F (-30 °C to +55 °C); below 95% non-condensing |
| Dimensions / weight |
17.7 x 17.3 x 5.1 in. (449.58 x 439.42 x 129.54 mm); 52.91 lb (24 kg) |
| Listing and FCC |
UL 2524 2nd Edition (SGS NRTL); FCC ID P3TDH7S-3A |
Compatibility and installation notes
- Works with a FLEX small DAS master: HONBDA-D-7S33A-M (DC) or HONBDA-A-7S33A-M (AC), each with two optical ports.
- Alarms (power, master and remote status) are reported through the master unit; configuration is done locally at the master over USB.
- Standards stated: IFC 2015, 2018, 2021; NFPA 72 2013; NFPA 1221 2016, 2019; NFPA compliant with dry contact alarms.
Related models
Documents
Specifications from Honeywell data sheet 9021-62129 Rev. B, 10/01/2022, FLEX Series BDA HONBDA-A/D-7S33A-M, 700/800 Small Public Safety Centric DAS. Manufacturer specifications are subject to change.
