Edwards GC-HDVMH Ceiling Mount Horn Strobe, Multi-Cd (95-177Cd), Temporal Hi/Lo Db Output, 24V - White
Genesis ceiling horn-strobe with a white housing and no text marking. It is the high-candela model: the strobe output is selectable at 95, 115, 150 or 177 cd with a switch on the front of the device, and the temporal horn has high/low dB settings. It mounts to a 4 in. square electrical box for indoor ceiling or wall use on 24 V notification circuits.
Key Features
- Field-selectable 95/115/150/177 cd strobe; setting stays visible after installation
- Temporal-tone horn with high or low dB output (low setting reduces output by about 5 dB)
- Low profile: 6.8 in. (173 mm) diameter, no visible mounting screws
- Single input for both horn and strobe; #18 to #12 AWG screw terminals
- Fits a standard 4 in. square box, 2-1/8 in. (54 mm) deep
- UL 1971 / UL 1638 strobe; indoor ceiling or wall applications only
Specifications
| Strobe output |
Selectable 95, 115, 150 or 177 cd |
| Operating voltage |
16-33 VDC filtered or 16-33 VDC FWR unfiltered (24 V nominal) |
| Housing color |
White |
| Marking |
None |
| Mounting |
North American 4 in. square box, 2-1/8 in. (54 mm) deep |
| Operating environment |
Indoor, 32-120 F (0-49 C), 93% RH |
| Agency listings |
UL 1638, UL 1971, ULC-S525/S526, CSFM, MEA, FM |
Compatible With
- G1M-RM Genesis Signal Master
- SIGA-CC1S / SIGA-MCC1S synchronization modules
- BPS6A / BPS10A booster power supplies
