4-NET-SM is an Edwards EST4 SFP network controller for single-mode, dual-fiber cabling (100Base-LX10, 1310 nm). EST4 network controllers are small form factor pluggable transceivers that set the physical media of the panel-to-panel link. The 4-NET-SM plugs into either SFP slot on a 4-CPU, 4-ANNCPU, 4-CPUGRPH or 4-NET-AD module and is hot-swappable.
Specifications
| Transceiver type |
100Base-LX10, single-mode, dual-fiber |
| Wavelength (TX/RX) |
1310 nm / 1310 nm |
| Fiber |
G.652 single-mode, 9 µm core |
| Cable distance |
8.7 miles (14 km) per E85014-0008; E85014-0003 states 6.2 miles (10 km) |
| Transmit power |
-15 to -8 dBm |
| Receive power |
-25 to -8 dBm |
| Max. channel insertion loss |
5 dB |
| Data speed |
100 Mbps TX/RX |
| Current (standby/alarm) |
5 mA at 24 VDC |
| Connector |
LC duplex |
| Operating environment |
32 to 120 °F (0 to 49 °C), 0 to 93% RH noncondensing |
| Agency certifications |
UL, ULC, FM, CSFM, EN54, CE, NYC Fire Dept. |
| Shipping weight |
0.248 lb (0.112 kg) |
Compatibility and installation notes
- Mounts in either of the two SFP slots on 4-CPU, 4-ANNCPU, 4-CPUGRPH and 4-NET-AD modules; hot-swappable.
- Order one 4-NET-SM for the "in" link from the previous node and a second for the "out" link to the next node; each supports one single-mode fiber pair.
- For panel-to-panel communication only. External network connections use 4-FWAL Series adapters.
- A single network link carries data, voice audio and firefighter telephone. Networks can be wired Class A, B, X or N.
Related models
-
4-NET-SMH: single-mode dual-fiber, 100Base-LX40 high output, 24.8 miles (40 km); needs at least 10 dB insertion loss.
-
4-NET-SMU and 4-NET-SMD: single-mode single-fiber bidirectional pair (LC simplex), used together.
-
4-NET-MM: multimode dual-fiber, 100Base-FX.
-
4-NET-CAT and 4-NET-TP: copper versions.
Documents
Specifications from Edwards data sheet E85014-0008, EST4 Network Controllers, Issue 3.0, and E85014-0003, EST4 Remote Annunciators, Issue 3.1. Manufacturer specifications are subject to change.
FAQ
Where does the 4-NET-SM install?
In either SFP slot on a 4-CPU, 4-ANNCPU, 4-CPUGRPH or 4-NET-AD module. It is hot-swappable.
How many are needed per panel?
One for the "in" link from the previous node and a second for the "out" link to the next node. Each supports one single-mode fiber pair.
How far can it reach?
Data sheet E85014-0008 gives 8.7 miles (14 km) on G.652 single-mode fiber, with a 5 dB maximum channel insertion loss.
What does the fiber link carry?
Data, voice audio and firefighter telephone on a single network link.
