E2S SP77-0001-A4-R is the multi-angle mounting bracket in A4 (316) stainless steel for E2S D1xB2 explosion-proof beacons with a red enclosure. The D1xB2 normally mounts on its integrated lugs or as a pendant; adding this optional bracket allows multi-directional mounting so the beacon can be aimed.
Specifications
| Part number |
SP77-0001-A4-R |
| Description |
Multi angle bracket A4 (316) for red enclosure |
| Material |
A4 (316) stainless steel |
| Enclosure color match |
Red |
Compatibility and installation notes
- Listed as an accessory for the D1xB2X10 10 joule xenon strobe beacon; the D1xB2 installation manual describes it as a ratchet-adjustable stainless steel wall bracket assembly, accessory part code SP77-0001.
- Besides this bracket, the beacon can be mounted on its two feet (lugs, each retained by two M5 screws) or conduit mounted through the 3/4 in. NPT entry in its base.
- Order the -R version for red beacon enclosures and the -G version for grey enclosures.
- Other D1xB2 accessories: SP65-0001-A4 pole mount bracket kit and SP65-0003-A4 sunshade, both A4 (316) stainless steel.
Related models
Documents
Specifications from E2S data sheet 1-21-203, D1xB2X10 Explosion Proof Xenon Strobe Beacon 10J (13 Jul 2026), and D1xB2 installation manual D191-00-201-IS Issue 9. Manufacturer specifications are subject to change.
