E2S D1XB2X10DC024MN1A1R/R is a D1xB2X10 explosion-proof 10 joule xenon strobe beacon in an LM6 marine-grade aluminum enclosure, approved to UL 1638 and CAN/ULC-S526 for fire alarm use. This configuration is the 24 Vdc unit with mixed NPT/M20 entries, nickel-plated brass stopping plugs, an A4 316 stainless steel guard, product version A approvals, a red enclosure and a red lens filter.
Specifications
| Part code decode |
D1xB2 / X10 / DC024 / M entries / N nickel-plated brass / 1 A4 316 stainless guard / A version / 1 standard / R red enclosure / R red lens |
| Source / energy |
Xenon strobe, 10 J |
| Flash rates |
1 Hz, 1.3 Hz, 1.5 Hz and double flash |
| Effective intensity |
69.81 cd, UL 1638 private mode fire (clear lens) |
| Voltage |
24 Vdc (20-28 Vdc) |
| Current at 24 Vdc |
605 mA nominal, 710 mA maximum; in-rush 753 mA within 6 ms |
| Cable entries |
Side: 2 x 3/4 in. NPT and 2 x M20x1.5; pendant: 1 x 3/4 in. NPT; stopping plugs included |
| Lens |
High-impact borosilicate glass with field-replaceable UV-stable polycarbonate red filter |
| Terminals |
0.5-2.5 mm2 (20-14 AWG), 12 AWG solid; duplicated |
| Hazardous locations (NEC) |
Class I Zone 1 AEx db IIC T4, Ta -55 to +80 C; Class I Div 1 Groups A-D T4; Class II Div 1 Groups E-G T4 |
| Ingress protection |
IP66/67; Type 4/4X/3R/13 |
| Safety integrity (version A) |
SIL1 and SIL2 Route 2H |
| Installation temperature |
-55 to +80 C (-67 to +176 F) |
| Weight |
3.2 kg / 7.1 lb |
Compatibility and installation notes
- Listings include UL/cUL/ULC file E245313 and CSFM 7300-2279:0508; UL Marine approved.
- Multi-beacon systems synchronize automatically.
- Mounts on its integrated lugs or as a pendant; for multi-directional mounting add bracket SP77-0001-A4-R (red enclosure).
- E2S states that all candela data is for a clear lens at optimum voltage; no figure is published for the red filter.
- Spares: SP77-0002 xenon flash tube assembly; SP77-0015-R mounting lugs, pack of 2, red.
Related models
Documents
Specifications from E2S data sheet 1-21-203, D1xB2X10 Explosion Proof Xenon Strobe Beacon 10J (13 Jul 2026). Manufacturer specifications are subject to change.
