Yuasa NP12-12 is a 12V sealed lead-acid battery rated 12.2Ah at the 20-hour rate, built with absorbed glass mat (AGM) technology and F2 Faston terminals. It belongs to the Yuasa NP/NPX range and is used as standby or backup power in fire and security equipment.
The sealed, non-spillable case lets the battery be mounted in more than one position. Typical uses named for this range include alarm systems, emergency lighting, UPS systems, CCTV, access control and other backup-power equipment.
Features
- Valve regulated AGM construction, maintenance-free and non-spillable
- Can be mounted in multiple positions
- Lead calcium grids, rechargeable
- Very low self-discharge, so it can sit in storage for long periods without permanent capacity loss
- Design life of up to 5 years at normal ambient temperature (77°F)
- F2 Faston terminals
Specifications
| Voltage |
12V DC |
| Capacity |
12.2Ah (20-hour rate) |
| Chemistry |
Sealed lead acid (SLA), rechargeable |
| Terminals |
F2 Faston |
| Depth |
5.9" |
| Height |
3.8" |
| Width |
3.9" |
| Certification |
RoHS; TAA compliant |
