Westell CV05-527-614 10dB Power Tapper, 138-960MHz -153 PIM, 200W, N/Female
The CV05-527-614 is the 10 dB model in Westell's CV05-500-614 series of public safety power tappers. The series covers 138-960 MHz (VHF, UHF, 700 and 800 MHz), handles 200 W average power and uses N female connectors. Tappers split RF power unequally between a through line and a coupled branch in a distributed antenna system.
Key Features
- Wide band: VHF/UHF/700/800 MHz, 138-960 MHz
- Low insertion loss and low VSWR
- Low passive intermodulation: -153 dBc @ 2 x 43 dBm
- 200 W average power
- IP65 compliant
- N female connectors
Specifications
| Coupling |
10 dB |
| Frequency range |
138-960 MHz |
| Impedance |
50 ohms |
| Average power |
200 W |
| PIM |
-153 dBc @ 2 x 43 dBm |
| Connectors |
N female |
| IP grade |
IP65 |
| Color |
Red |
Compatible With
- Public safety VHF/UHF/700/800 MHz DAS / BDA (ERCES) systems
