The Westell CS40-734834-00D-AR ProtectLink Optical Remote is a high-performance public safety signal enhancement solution designed to extend coverage for ProtectLink Class A BDAs
Operating across the 700-800 MHz public safety bands, this optical remote delivers 2.5 Watts per band with automatic fiber-loss compensation for fast and reliable installation.
Engineered for NFPA and IFC compliance, the Westell ProtectLink Optical Remote expands BDA coverage while maintaining signal integrity, making it ideal for commercial buildings, hospitals, campuses, tunnels, and public safety applications.
This remote unit supports single-band or dual-band configurations and provides digital and analog modulation support, ensuring flexible deployment across a wide range of public safety communication systems.
Key Features
• 2.5 Watts output per band
• Supports 700-800 MHz public safety bands including FirstNet
• Automatic fiber-loss adjustment for easy installation
• Extends ProtectLink BDA coverage footprint
• Requires only a single strand of fiber
• Fully NFPA and IFC compliant
• Supports digital and analog modulation
• Built-in battery charging and alarm monitoring
• Mirrors filters from master BDA
• Listed to UL2524
• 3-year manufacturer warranty
Product Overview
The Westell ProtectLink Optical Remote provides scalable public safety coverage by expanding signal distribution from a master ProtectLink Class A BDA. The system automatically compensates for fiber losses, reducing setup time and eliminating manual adjustments.
This solution is ideal for:
• High-rise buildings
• Hospitals
• Airports
• Universities
• Warehouses
• Tunnels and underground facilities
• Public safety infrastructure
Technical Specifications
Brand: Westell
Model: CS40-734834-00D-AR
Series: ProtectLink
Frequency Range: 700-800 MHz
Output Power: 2.5 Watts per band
Compliance: NFPA, IFC, UL2524
Configuration: Single-band or dual-band
Fiber Requirement: Single strand
Warranty: 3 Years
