Each VESDA-E VEA detector draws air from rooms through microbore tubes that end at small ceiling sampling points. The VSP-980-B22 is a pack of 22 black 6 mm standard sampling points for that network, and the black finish suits dark ceilings where a discreet fitting is wanted.
Key Features
- Pack of 22 standard sampling points for 6 mm microbore tubes
- Black finish
- Swivel-joint inlet for flexible tube orientation
- Blind mounting: no ceiling-void access needed once tubes are run through the ceiling
- Screws directly to the ceiling or mounts with the included retainer
- Fully supervised and cleaned automatically by the VEA detector
Specifications
-
Manufacturer: VESDA (Xtralis)
-
Part Number: VSP-980-B22
-
Type: VESDA-E VEA standard sampling point
-
Tube Size: 6 mm
-
Color: Black
-
Quantity: 22 per pack
Compatibility
For VESDA-E VEA aspirating smoke detectors with 6 mm microbore sampling tubes, in ceilings with a void above them. For exposed tube runs, use the VSP-982 surface-mount sampling points instead.
