Vesda VSP-972 is a single replacement filter cartridge for the VESDA-E VEA aspirating smoke detector. It is one of the field replaceable parts of the detector and filters coarse particles out of the air sample before it reaches the detection chamber.
Working with the clean air barriers, the filter protects the optics to keep detection performance stable over the detector life. The cartridge is smart: it retains its own dust count and remaining filter life, so replacement can be scheduled instead of found during a fault. It cannot be cleaned and must be replaced with a new cartridge.
Specifications
| Fits |
VESDA-E VEA detector |
| Quantity |
1 cartridge |
| Dimensions (W x H x D) |
2.83 x 4.25 x 0.5 in. (72 x 108 x 13 mm) |
| Filtering |
Coarse particle |
| Service |
Field replaceable, not cleanable |
Features
- Field replaceable filter
- Coarse particle filtering
- Filtration and optical protection with clean air barriers
- Smart on-board memory for dust count and remaining filter life
Related models
-
VSP-962: single filter cartridge for VESDA-E VEP, VEU and VES detectors
-
VSP-962-20: pack of 20 VSP-962 cartridges
Documents
FAQ
Which detector does the VSP-972 fit?
The VSP-972 is the filter cartridge for the VESDA-E VEA detector. VEP, VEU and VES detectors use the VSP-962 instead.
Can the cartridge be cleaned?
No. The VESDA-E filter cartridge cannot be cleaned and must be replaced with a new one.
How do I know when to replace it?
The smart on-board filter retains its dust count and remaining filter life, which allows maintenance to be planned ahead.
