VESDA VSP-610-US Tamper Proof Sampling Point, 1In./ 25Mm Rigid or Flexible Conduit
Tamper-proof sampling point for Xtralis / VESDA aspirating smoke detection, in the version for imperial pipe. It is a stainless steel ceiling fitting fed by rigid or flexible conduit-size pipe (1 in / 25 mm inlet), intended for places where sampling points are exposed to vandalism or abuse. The mesh inlet can be serviced, and the sampling hole size is set by a separate in-line flow restrictor.
Key Features
- Tamper-proof, concealed design for areas prone to tampering
- Stainless steel (SUS304) construction
- Pipe inlet 25 mm (1 in); rigid or flexible conduit
- Fixed to the ceiling material with 4 screws
- Serviceable mesh inlet
- Needs a flow restrictor (VSP-870-US) in the pipe to give the required sampling hole size
- Typical uses named by Xtralis: correctional and detention facilities, hospitals, luxury accommodation, heavy industry
Specifications
| Pipe inlet |
25 mm (1 in), imperial pipe version |
| Material |
Stainless steel SUS304 |
| Fixing |
4 screws |
Compatible With
- Xtralis VESDA / VESDA-E aspirating smoke detectors
- VSP-870-US in-line flow restrictor assembly - US
- VSP-871 spare flow restrictor discs
