VESDA VSP-103 — scanner relay processor module (DRP) for VESDA LaserSCANNER aspirating smoke detectors.
In a VESDA system the relay contacts live on a termination card, and that card has no intelligence of its own: it must sit behind either a display module or a relay processor board. Where relays are mounted away from the detector, in a remote box or a 19 in. sub rack, and no display module fills that position, the VSP-103 supplies the processing the relays need.
- Scanner version, for LaserSCANNER (VLS) detectors, which split one VESDA zone into four sampling sectors
- Required where remote relays are used and no display module is fitted
- One relay processor board per sub rack position that carries relays
- Holds no relay contacts itself; relay count comes from the termination card, seven or twelve
- VLS relay contacts are rated 2 A at 30 VDC
Order against the right neighbours: VSP-102 is the non-scanner relay processor for LaserPLUS (VLP) detectors, while the cards themselves are VSP-008 seven relay remote and VSP-208 twelve relay remote for VLS.
