Surface P-Clip Stainless Steel (pack of 100)
The Thermocable A1329 is a stainless steel P-clip for surface-fixing ProReact linear heat detection cable, supplied in packs of 100. Thermocable states its stainless steel clips are suitable for indoor and outdoor use, including locations where the clip may be exposed to harsh chemicals such as hydrocarbons or a caustic environment. A silicone sleeve is used between the clip and the cable to protect it from abrasion, pressure and heat transfer from the metal fixing.
Key Features
- Stainless steel P-clip for surface mounting of linear heat detection cable
- Suitable for indoor and outdoor use and chemically harsh environments (per manufacturer)
- Non-combustible metal fixing, in line with BS 5839-1 guidance on cable supports cited by the manufacturer
- High-temperature silicone sleeves are packaged as standard with clips
- Supplied as a pack of 100
Specifications
| Material |
Stainless steel |
| Size |
12 mm x 22 mm |
| Operating temperature |
Up to 815°C |
| Pack quantity |
100 |
| Pack weight (net / gross) |
340 g / 355 g |
Compatible With
- Thermocable ProReact Digital linear heat detection cable
- Thermocable ProReact Analogue linear heat detection cable
