System Sensor SA-WBB — SpectrAlert Advance wall-mount outdoor weatherproof metal back box, red.
Outdoor SpectrAlert Advance appliances stay outdoor-listed only when installed in their weatherproof back box, so on an exterior wall the SA-WBB is part of the listing, not an optional accessory. Buy it separately when a box is damaged or corroded, or when boxes must be set and piped at rough-in.
- 5.7" L × 5.1" W × 2.0" D (145 × 130 × 51 mm)
- Weatherproof per NEMA 4X and IP56
- Outdoor SpectrAlert Advance devices rated –40°F to 151°F (–40°C to 66°C)
- Ceiling-mount equivalent is the SA-WBBC
This is the SpectrAlert Advance box. The plain WBB sold elsewhere on this site is the legacy box — 4.33" × 1.55" × 4.33", UL certified only for the older H12/24K, S1224MCK, P1224MCK and P12015K SpectrAlert appliances and SSM24 / SSV120 bells. The two are not interchangeable, and fitting an unlisted back box voids the outdoor UL designation. Replacing a standard outdoor unit means replacing both device and box.
