Space Age SSU-MR-101/C is a single-pole, double-throw (SPDT) control relay from the MR Series with a 10 A resistive contact rating and a gray enclosure. One relay can be energized from any of several control voltages by wiring to the matching input terminals.
It suits local contacts for system status, remote contacts for controlling electrical loads, and general purpose switching in HVAC, temperature control, fire alarm, security, energy management, and lighting control systems.
Features
- SPDT contacts rated 10 A resistive
- Control input of 24 V AC/DC, 115/120 V AC, or 230 V AC
- Red LED shows when the coil is energized
- Modules can be snapped apart from a standard 4-position assembly
- DC control inputs are polarized
- Dust-resistant enclosure with LED viewing port
- UL certified
Specifications
| Contact type |
SPDT |
| Number of positions |
1 |
| Contact rating |
10 A |
| Color |
Gray |
| Height |
5.1 in |
| Width |
3.1 in |
| Depth |
1.5 in |
