As part of the Simplex TrueAlert addressable family, the 4906-9230 is a ceiling-mount horn/strobe with a multi-candela xenon strobe, in a white housing with "FIRE" lettering. A TrueAlert addressable signaling line circuit powers, supervises and controls each appliance individually. Horn and strobe run separately over the same two wires.
Key Features
- Strobe set to 15, 30, 75 or 110 cd with a plug at the appliance, or programmed from a 4100U panel with TPS
- Synchronized 1 Hz flash rate
- Horn sounds temporal, March Time or continuous, with high or low output (about 5 dBA apart)
- Supervision to each appliance allows T-tapping on Class B circuits
- With a 4100U and TPS, TrueNAC voltage-drop diagnostics and device reports are available
Specifications
-
Manufacturer: Simplex
-
Part Number: 4906-9230
-
Mounting: Ceiling
-
Color: White housing, "FIRE" lettering
-
Candela: 15 / 30 / 75 / 110 cd
-
Max RMS Current (ceiling, horn steady): 82 mA at 15 cd; 135 mA at 30 cd; 249 mA at 75 cd; 335 mA at 110 cd
-
Rated Voltage: 17 to 31 VRMS (UL special application)
-
Horn Output: 2400–3700 Hz sweep
-
Dimensions: 4-3/4 in L x 6-7/8 in W x 2-5/8 in D (121 x 175 x 67 mm)
-
Environment: 32°F to 122°F; 10% to 93% RH non-condensing
-
Wire Size: 18–12 AWG
-
Certifications: Strobe UL 1971, horn UL 464; UL, ULC, CSFM (7125-0026:239) certified; FM approved
Compatibility
Works with the 4100U TrueAlert Addressable Power Supply (TPS) and the TrueAlert Addressable Controller (4009T). It can share an SLC with fixed-candela TrueAlert addressable strobes. TrueNAC diagnostics require 4100U software revision 12.04 or higher.
Documents
FAQ
Which control equipment does it work with?
TrueAlert addressable SLCs, such as the 4100U TrueAlert Addressable Power Supply (TPS) and the TrueAlert Addressable Controller (4009T).
How is the candela set?
To 15, 30, 75 or 110 cd, with a plug at the appliance or programmed from a 4100U panel with TPS.
Is there an adapter for surface mounted boxes?
Yes. The 4905-9915 white adapter (4905-9916 in red) is recommended for surface mounted boxes and covers 1-1/2 in. deep boxes.
What is the red version?
The 4906-9228 is the same addressable horn with multi-candela strobe in red with white FIRE lettering.
