Simplex 4905-9946 is a red surface-mount adapter skirt for Simplex wall-mount speaker/visible (S/V) notification appliances. It is required when an S/V appliance is mounted to a surface-mounted 4 in. square electrical box, 1-1/2 in. deep, with a 1-1/2 in. deep extension. The skirt covers the box and gives the appliance a finished, color-matched base, and conduit knockouts are provided on all four sides.
Specifications
| Type |
Surface mount adapter skirt |
| Color |
Red |
| Dimensions (H x W x D) |
7-3/4 x 5-3/8 x 3-3/16 in. (197 x 137 x 81 mm) |
| Depth with S/V installed |
5-7/8 in. (149 mm) |
| Box requirement |
4 in. square, 1-1/2 in. deep surface box with 1-1/2 in. extension |
| Knockouts |
Conduit knockouts on all four sides |
Compatible with
- Wall-mount TrueAlert S/V appliances 4903-9356 through 4903-9361
- Wall-mount multi-candela S/V appliances 4906-9151 and 4906-9153
The white version of this skirt is 4905-9947.
