Simplex 4100-9706 — 4100ES Master Controller supplied with the color ES Touch Screen Display user interface.
This is the controller a 4100ES panel is built around, not an add-on display. Simplex ships it as one selection combining the 32-bit Master Controller, the CPU card holding the site program, an IDNet 2 loop card and the ES Power Supply.
- Master Controller, CPU card, IDNet 2 card for up to 250 addressable points and the ES Power Supply at 120 to 240 V, 50/60 Hz
- Supply section carries a 24 V auxiliary relay, a 24 V 2 A auxiliary tap or simple NAC and a 110 Ah battery charger
- External RUI+ interface for remote annunciator modules
- 8 in. (203 mm) diagonal resistive color touch screen, 800 × 600 pixels, eight events without scrolling
- Dual language support, required language switch selectable
- 362 mA supervisory, 441 mA alarm, excluding IDNet device current; UL, ULC and CSFM certified
The siblings differ only in the operator interface: 4100-9701 carries a two-line by 40-character monochrome English display, 4100-9702 that display in Canadian French, and 4100-9709 none. Adding this screen to an installed panel is the 4100-7165 upgrade kit.
FAQ
What is included with the 4100-9706?
The 32-bit Master Controller, the CPU card, an IDNet 2 loop card for up to 250 addressable points and the ES Power Supply at 120 to 240 V, 50/60 Hz.
How does it differ from the 4100-9701?
Only the user interface: the 4100-9706 has the color ES Touch Screen Display, while the 4100-9701 has a two-line by 40-character monochrome display.
Can the touch screen be added to an installed panel?
Yes, with the 4100-7165 upgrade kit.
