Simplex 4100-9211 — 4100ES master controller assembly with LCD and operator interface, for 220–240 VAC input, UL certified.
This assembly equips the top bay of a 4100ES fire alarm control panel. It holds the 32-bit master controller, a two-line by 40-character display, the 9 A system power supply and charger, and the on-board circuits. The back box and door or retainer are ordered separately.
- 9 A system power supply and charger; 2 A maximum at 204–264 VAC, 50/60 Hz, with separate 220/230/240 VAC taps
- On-board IDNet channel for up to 250 addressable points, Class A or B
- Three on-board NACs rated 3 A for special application appliances and 2 A for regulated 24 DC
- Auxiliary relay and external RUI+ port, isolated or un-isolated
- 373 mA supervisory and 470 mA alarm, before IDNet device loads
- UL certified to charge 6.2 to 110 Ah batteries (above 50 Ah in a remote cabinet)
The 4100-9111 is the 120 VAC version. The 4100-9230 is the 220–240 VAC version with no display or operator interface. The ES-PS master controllers such as the 4100-9701 use a different power supply and are separate parts.
