Simplex 4100-6056 — Wired Media Card for 4100U and 4100ES network interface and physical bridge modules.
A 4100 node does not meet the wire directly: the network interface card or TCP/IP physical bridge presents a left and a right port, and each port takes a media card that sets the physical medium. This is the twisted-pair choice; a fiber card is picked for electrically noisy or long external runs. Two media cards fit each host card and they may be mixed, so one port can be copper and the other fiber.
- Simplex assembly 565-413; 40-pin connector to the host card
- Power 4.75 to 5.25 VDC at 170 mA maximum
- 18 AWG unshielded twisted pair or 24 AWG twisted pair telephone cable; shielded cable is allowed, and shielding plus circuit protection are required when wiring leaves the building
- Shield terminates to chassis earth on the left port only
- Operating 32° to 120°F (0° to 49°C)
One card, two interface generations — and the generation decides its fiber sibling. On the 4100/4120-6014 NIC that is the 4100-6057; on the 4100-6078 or 4100-6061 interface it is the 4120 duplex fiber family, 4100-6301/-6302 single-mode and 4100-6303/-6304 multi-mode, paired left port to right port. 4100/4120-0142 is the wired card for older non-4100U panels.
Documents
FAQ
Which network cards does the 4100-6056 mount on?
It mounts on the 4100-6078 or 4100-6061 modular network interface, and is also used with the 4190 network system integrator.
How far can a wired network run?
With 18 AWG twisted pair, up to 17,000 ft at 9600 baud or 10,000 ft at 57.6 k baud. With 24 AWG telephone cable, up to 12,000 ft at 9600 baud or 7,000 ft at 57.6 k baud.
Do I need shielded cable?
Unshielded twisted pair is allowed inside the building. Shielded cable and circuit protection are required when the wiring leaves the building.
Can copper and fiber be mixed on one network card?
Yes. Different types of media cards can be fitted to the same network interface card, such as a wired card on one port and a fiber card on the other.
