The Simplex 4100-5325 EPS Power Supply 120V is an extended power supply module designed for use with Simplex 4100ES fire alarm control panels.
This power supply expands system capacity by providing additional power and control for notification appliances and system modules, making it ideal for large or expanding fire alarm installations.
The 4100-5325 EPS delivers reliable 120VAC input power and provides regulated DC output for system components. It is engineered to support TrueAlert ES addressable notification appliances and other system devices, ensuring consistent performance and system reliability.
Key Features
• Extended power supply for Simplex 4100ES fire alarm systems
• 120VAC input, 50/60 Hz operation
• Provides additional system power and expansion capability
• Supports TrueAlert ES addressable notification appliances
• Designed for expansion bays in 4100ES systems
• Reliable regulated DC output
• Compatible with Simplex 4100ES architecture
• Designed for large and expandable fire alarm systems
Advanced System Expansion
The Simplex 4100-5325 Extended Power Supply is designed to expand system power capacity in Simplex 4100ES control panels. This allows additional notification circuits and modules to be added without replacing the primary system power supply.
The EPS module provides three signaling line circuits for control and power of addressable notification appliances, improving system flexibility and scalability. (FireAlarm.com)
Specifications
• Model: 4100-5325
• Type: Extended Power Supply (EPS)
• Input Voltage: 120 VAC, 50/60 Hz
• Output Voltage: 29 VDC
• Output Current: Up to 9 A
• Operating Temperature: 32°F to 120°F (0°C to 49°C)
• Application: Simplex 4100ES Fire Alarm Systems (Scribd)
Compatibility
The Simplex 4100-5325 is designed for use with:
• Simplex 4100ES Fire Alarm Control Panels
• TrueAlert ES notification appliances
• Expansion bays in 4100ES systems
• Additional system modules and accessories (Interamsa | Inversiones Interamericanas)
Applications
Ideal for:
• Large commercial buildings
• Hospitals
• Universities
• Industrial facilities
• Campus environments
• Multi building fire alarm networks
Why Choose the Simplex 4100-5325?
The Simplex 4100-5325 EPS Power Supply provides reliable power expansion for advanced fire alarm systems. Designed specifically for Simplex 4100ES panels, it delivers scalable performance and dependable operation for complex fire protection installations.
Brand: Simplex
Model: 4100-5325
Type: Extended Power Supply (EPS)
Input Voltage: 120V
Compatibility: Simplex 4100ES Fire Alarm Systems
