Simplex 4100-1315 is a primary 100 W analog audio amplifier with a 70.7 VRMS output for 4100ES fire alarm control panels. It runs from 120 VAC, 60 Hz, is UL certified, and includes six on-board Class B audio notification appliance circuits for speaker wiring. The 25 VRMS version is the 4100-1314.
Specifications
| Output |
70.7 VRMS, 100 W |
| Input |
120 VAC, 60 Hz |
| Audio circuits |
Six Class B NACs, 100 speakers maximum |
| NAC rating |
1.414 A at 70.7 VRMS (100 W) |
| Supervisory current |
400 mA (analog) with power stage supervised; 85 mA in low power mode |
| Alarm current |
9.6 A with continuous horn tone; 3.8 A average with temporal pattern horn |
| Built-in tone |
500 Hz temporal pattern horn tone |
| Amplifier power per cabinet |
300 W maximum |
Features
- Power-limited linear output stage
- Supervision compares output level to input level in real time
- On-board test switch for backup operation and overcurrent protection
- Reports voltage and current values to the control panel operator interface
