Simplex 4100-1288 is a 64 LED / 64 switch controller module with mounting plate for Simplex 4100ES panels. It controls up to 64 LEDs and interfaces to up to 64 switches on panel-mounted LED/switch modules, mounting on a bracket on the back of those modules.
The module has provisions for one 4100-1289 controller, which mounts on the 4100-1288's extra space and adds 64 more LEDs and 64 more switches. A maximum of two controllers can be used per bay, and controllers and their connected modules must be in the same bay.
Specifications
| Capacity |
64 LEDs and 64 switches |
| Input voltage |
19 to 33 VDC, from control panel |
| Current, no LEDs on |
20 mA at 24 VDC |
| Current, all 64 LEDs on |
210 mA at 24 VDC (approx. 3 mA per LED) |
| Mounting |
Bracket attaches to the back of the LED/switch modules |
| Controllers per bay |
Maximum of two |
| Bay location |
Slots 1 and 2 or slots 3 and 4 |
| Clearance behind |
Accepts low profile 4100ES modules only |
Installation notes
- Refer to Simplex installation instructions 574-843 for LED/switch module details
- Where the controller shares a bay with two Flex-35/50 amplifiers and an SPS, a 4100-0636 power/communications harness kit and 4100-0641 flex cable are required
Related models
- 4100-1289: 64/64 controller module without mounting plate
- 4100-1290: 24 point I/O module
Documents
FAQ
What does the 4100-1288 control?
Up to 64 LEDs and up to 64 switches on 4100ES panel-mounted LED/switch modules. It mounts behind the LED/switch modules on its mounting plate.
Can it be expanded?
Yes. It has provisions for one 4100-1289 controller module, which mounts on the extra space of the 4100-1288 and controls an additional 64 LEDs and 64 switches.
How many controllers can be used per bay?
A maximum of two per bay, each controlling LED/switch modules within that bay only. Controllers and their modules must be in the same bay.
How much current does it draw?
20 mA at 24 VDC with no LEDs on, and about 210 mA with all 64 LEDs on (approx. 3 mA per LED).
