Simplex 4098-9771 TrueAlarm CO Sensor Base with Sounder — addressable carbon monoxide base with an integral piezoelectric sounder.
This base senses carbon monoxide, not smoke. It ships without a sensor head and needs a TrueAlarm photoelectric, photo/heat or heat sensor ordered separately to work. Base and head use one IDNet address, and a 4100ES or 4010ES can correlate CO and photoelectric readings to cut nuisance alarms or speed fire detection.
- Head ordered separately: 4098-9714 photo, 4098-9754 photo/heat or 4098-9733 heat
- Sensor power from IDNet; sounder needs separate 24 VDC or NAC wiring
- Sounder 18–32 VDC, 17 mA at 24 VDC, 88 dBA minimum at 10 ft per UL 464
- Requires 4100ES/4010ES software 2.01.02+, or 4100U software 12.05+
- Certified to UL 268 and UL 2075; ULC to CSA 6.19-01
The CO element expires. A built-in date code drives Almost Expired troubles at 12 and 6 months, then Expired: 10 years on 4100ES/4010ES, 5 on 4100U. Budget for the 4098-9747 replacement cartridge (CORC), not a new base.
Documents
FAQ
Is a sensor head included?
No. The 4098-9771 is a CO sensor base and needs a separately ordered TrueAlarm sensor such as the 4098-9714 photoelectric, 4098-9754 photo/heat or 4098-9733 heat sensor.
What is the difference from the 4098-9770?
The 4098-9770 is the standard CO base; the 4098-9771 adds a piezoelectric sounder rated 88 dBA minimum at 10 ft.
How long does the CO sensing element last?
End of useful CO sensor life is based on a set 10-year period. 4007ES, 4010ES and 4100ES panels give a 10-year end-of-life indication, 4100U panels a 5-year one, and the 4098-9747 CO replacement cartridge is the replacement part.
Does the sounder need separate power?
Yes. The sounder needs 24 VDC or NAC wiring in addition to the IDNet connection.
