Simplex 4090-9121 is a Security Monitor IAM (individual addressable module) for 4100ES, 4100U and 4010ES panels with IDNet communications. It takes its power and address from the two-wire IDNet circuit.
The module supervises up to five normally closed or normally open dry-contact security devices, such as door or window switches, and reports Open, Normal, Abnormal and Short conditions to the panel.
Features
- Addressable security monitor module on an IDNet circuit
- Monitors up to 5 N.C. (series) or N.O. (parallel) dry contacts
- Reports Open, Normal, Abnormal and Short conditions
- Wiring to the contacts up to 500 ft
- Compact sealed housing
- UL 1076 certified
Specifications
| Compatible panels |
4100ES, 4100U, 4010ES (IDNet) |
| Addresses |
1 |
| Load |
2 unit loads |
| Wiring |
18 to 14 AWG screw terminals |
| Dimensions |
1 9/16 W x 1 3/4 H x 1 1/4 D in. (40 x 44 x 32 mm) |
| Temperature |
32°F to 120°F (0°C to 49°C), indoor |
| Humidity |
Up to 93% RH at 100°F |
| Standard |
UL 1076 |
Specifications taken from the manufacturer data sheet S4090-0004, 4090-9121 Security Monitor IAM.
