Simplex 4010-9922 — modular Network Interface Card (NIC) for the Simplex 4010ES fire alarm control panel. One card is required per 4120 network node.
The NIC puts a 4010ES on a Simplex 4120 fire alarm network so it shares alarm, trouble and control information with the other panels in the building. It does not communicate on its own: it carries two media cards, wired or fiber optic, which are ordered separately.
Specifications
| Model |
4010-9922 |
| Type |
Modular network interface card |
| Network |
Simplex 4120 fire alarm network |
| Panel |
4010ES |
| Mounting space |
2 vertical blocks |
| Media cards |
Two required, ordered separately (maximum 2 per card) |
| Current |
30 mA |
Installation notes
- Wired media card for 4010ES: 4010-9818 (55 mA)
- Fiber media cards: 4010-6301 left port and 4010-6302 right port single-mode; 4010-6303 left port and 4010-6304 right port multi-mode
- Fiber connections require left port to right port pairing, with a maximum of one left-port and one right-port card per NIC
- Static-sensitive board: handle by the edges with a grounded wrist strap
Related models
- 4100-6078: network interface card for 4100ES and 4100U
Documents
FAQ
Are media cards included?
No. The 4010-9922 requires two media cards ordered separately: the 4010-9818 wired card or 4010-6301 to 4010-6304 fiber cards.
How much space does it take?
It requires two vertical blocks in the 4010ES and draws 30 mA.
Can it be used in a 4100ES?
No. For 4100ES and 4100U panels, use the 4100-6078 modular network interface card.
Can single-mode and multi-mode fiber be mixed?
Each NIC takes a maximum of one left-port and one right-port duplex fiber card, and field connections must pair a left port to a right port.
