Simplex 4010-9521 — 4010ES addressable fire alarm basic control unit in a red two-bay cabinet, with a 2x40 character LCD operator interface and 220 to 240 VAC supply.
This is the international-mains member of the two-bay 4010ES range, and a complete control unit rather than a card: Simplex states box and door assemblies are included with basic control unit assemblies. Capacity is split across two channels.
- One two-loop isolated IDNet2 channel plus one four-loop IDNet 2+2 module, Class A or B
- Support for up to 500 addressable IDNet points; each channel carries up to 250
- 220 VAC to 240 VAC, English, listed UL and FM
- 8 A supply with up to 2 A auxiliary, four Class A or Class B NACs rated 3 A each
- Supervisory 391 mA, alarm 545 mA; consumes 3 of the 20 card addresses
- Two-bay box 40 × 24 × 6-29/32 in., NEMA 1 and IP 30
4010-9522 is the identical unit in platinum, and 4010-9421 and 4010-9422 are the same build at 120 VAC; the 4010-9435 substitutes an ES Touch Screen interface. Batteries are not included, and the 50 Ah this cabinet allows requires the 4100-0650 battery shelf.
