Simplex 2080-9057 — surface mount fire suppression system abort switch with red mounting box.
A releasing system peripheral. The plate reads PUSH AND HOLD FIRE SUPPRESSION SYSTEM ABORT, so operation is a held, dead-man style momentary action, not a latching disconnect. Simplex wires it through an IDNet addressable interface module such as the Supervised IAM 4090-9001, on 4010ES, 4100ES and 4100U panels.
- Momentary pushbutton on a stainless steel single-gang plate, with a removable protective collar
- Red surface box supplied, gasket fitted
- Three position contact block housing, one block fitted: silver contacts, 1 N.O. and 1 N.C., 2 A resistive at 30 VDC
- Terminal blocks for in and out wiring, 18 to 14 AWG
- Switch 4-1/2 × 2-3/4 in.; box 4-13/16 × 3 in.
- 32° to 120°F (0° to 49°C)
- UL, ULC, CSFM listed; MEA (NYC) accepted
Check the model row first. The 2080-9056 is the flush version, without the box. For current limited operation on 4004R Series panels Simplex specifies 2080-9067 (flush) and 2080-9068 (surface), adding a 1.2 kΩ 1 W resistor; the 2080-9057 has none. The 2080-9061 adds a contact block.
