Silent Knight 068200BD (68200BD) Replacement Board for the Silent Knight 6820 Fire Alarm Control Panel
068200BD: 6820 Addressable Fire Alarm Control Panel, 1110 Point, Replacement Board
The 1,110 point addressable fire alarm control panels include connected panel options, enhanced communications, wireless detection, and other advanced features. Allows connection up to 17 panels with convenient single point communications. Copper wire or fiber-optic cable panel connectivity can be used within the same linked system. Multiple signal line circuits (SLCs) can be used within one system limited only by maximum points available.
Key Features
- Connect up to 17 panels with convenient single point communications Copper wire or fiber optic cable panel connectivity can be used within the same linked system
- Multiple Signal Line Circuits (SLCs) can be used within one system limited only by maximum points available
- Built-in dual path IP and POTs communication for reliable dual path backup
- Built-in USB interface for convenient and speedy programming
- SWIFT® capable for wireless detection
- Convenient field-upgradeable firmware
- Supports up to 16 remote annunciators
- Programmable date setting for automatic and convenient Daylight Saving Time changes
- 4 x 20 annunciator with 80 character display and large easy-use keypad
- Includes access to Jumpstart™, HFSS programming software and the SKST selection tool
Documents
FAQ
What is the 068200BD?
It is the replacement board for the Silent Knight 6820 addressable fire alarm control panel.
How many points does the 6820 support?
One built-in SLC supports 159 SK detectors and 159 SK modules, or 127 Hochiki SD devices. With added loops the panel reaches 1110 SK or 635 SD points.
Does the 6820 have a built-in communicator?
Yes. The built-in DACT is dual technology, IP and POTS, with optional cellular reporting.
How many notification circuits does it have?
Six onboard Flexput circuits, each configurable as a notification output or auxiliary power.
