Siemens ST-CMC-CW-MNS-ALERT (S54301-Z94-A1) Mass Notification Strobe, Ceiling Mount, White, Clear Lens, ALERT Lettering, 15/30/75/95 cd

 Ceiling models are available with field-selectable, CLEAR-lens Candela settings of 15 / 30 / 75 / 95cd  Wall-mount models are available with field-selectable, CLEAR-lens Candela settings of 15 / 30 / 75 / 110cd  Ceiling models are available with field-selectable, AMBER-lens Candela settings of 11 / 22 / 56 / 71cd  Wall-mount models are available with field-selectable, AMBER-lens Candela settings of 11 / 22 / 56 / 82cd

Key Features

• The Model ST-series of strobes, used in correlation to mass-notification appliances, are a cost-
• Strobes are available in AMBER and CLEAR lens
• Strobes operate from 16 to 33VDC [using filtered or Full-Wave Rectified (FWR) voltage]
• Intensity options for AMBER-lens strobes include multi-Candela models with four (4)
• Strobes can be synchronized using the Siemens DSC sync modules, and are utilized
• Strobe appliances are Siemens Series ST Strobes or approved equals to be used
• All inputs shall employ terminals that accept #12 to #18 AWG sizes
• Strobe intensity, where multi-Candela appliances are specified, shall have field-selectable
• Selector switch for selecting the candela is tamper-resistant
• The strobes shall not drift out of synchronization at any time during operation

Specifications

Documents & Downloads

• ST- Mass Notification Clear and Amber Lens Standalone Strobe Appliances, Data Sheet (Data Sheet)
