Siemens SL2MTSWR-F (S54329-F237-A1) — indoor wall-mount multi-tone strobe, clear lens, red faceplate, FIRE lettering.
The appliance pairs a field-configurable tone generator with an LED strobe on a four-wire connection, so the audible and visible halves run in unison on one circuit or independently on two. Tone, volume and candela are set without tools.
- Six candela settings: 15, 30, 75, 110, 135 and 185 cd, drawing 0.022 A at 15 cd up to 0.185 A at 185 cd
- Eight tones — horn, bell, march time, Code 3 horn, Code 3 tone, slow whoop, siren, hi/lo
- Horn tone 91 dBA at HI and 86 dBA at STD, reverberant at 10 ft per UL 464, at 24 V
- Regulated 16 to 33 VDC or 16 to 33 VRMS full-wave rectified; #12 to #18 AWG
- Appliance 6.35 x 4.56 x 1.54 in. with a 5.25 x 4.58 x 1.4 in. trim plate; about 1.1 lb
- 32 to 122 °F indoors only; at most 105 SL2 strobes per circuit
SL2MTSWW-F is the white version, and SL2MTSWR-FB, SL2MTSWR-A and SL2MTSWR-N carry the pictogram, AGENT and unlettered faceplates. SL2SPSWR-F looks almost identical but is a speaker strobe fed from a 25 or 70 V audio riser.
