Siemens PAD5-6A — complete 6 A PAD-5 addressable power supply kit: black one-height-unit enclosure, PAD-5-MB main board and FP2011-U1 170 W supply.
The PAD-5 extends notification power on a Siemens Modular fire alarm panel. Its main board sits on the P2 loop of an XDLC device loop card and takes one address, so the panel sees its status in real time and controls each output. Batteries are not among the three items Siemens lists in the kit.
- Kit: PAB-ENCL black 1HU enclosure, PAD-5-MB main board with one adapter plate, FP2011-U1 170 W supply
- 24 VDC at 6 A total with the FP2011-U1; 3 A max per circuit
- Four Class B or two Class A NACs standard; 3 A auxiliary output
- Built-in strobe sync; steady, Temporal 3, Temporal 4 and March Time coding
- End-of-line values of 2.2 to 24 kΩ recognised automatically
- 1HU unit 16.0 × 24.0 × 3.50 in.; 32 to 120 °F; indoor, dry
The PAD5-6A-R is the same kit in the red PAB-ENCL-R, and the PAD5-9A uses the 300 W FP2012-U1 for 9 A. The PAD-5-CLSA card, which adds circuits and releasing service, is ordered separately.
Documents
FAQ
What is included in the PAD5-6A?
It is the complete 6 A PAD-5 unit: a 1HU enclosure, the PAD-5-MB main board and the FP2011-U1 power supply, which provides up to 6 A of NAC power.
How does it connect to the panel?
The PAD-5-MB main board connects to the P2 loop of a Siemens XDLC device loop card on a Siemens Modular panel and uses one address, set with the DPU programmer.
How many NACs does it have?
Four Class B or two Class A NACs are standard, rated 3 A each; the PAD-5-CLSA adds four more Class B or two Class A circuits.
What batteries can it charge?
The internal charger supports batteries up to 18 Ah in the 1HU enclosure, and up to 100 Ah in an external BB-55 Series battery box.
