CARDCAGE 2 SLOTS ALL CARDS CABMP 1 POSITION
The CC-2 is the two-slot card cage for Siemens FireFinder XLS, Desigo Fire Safety Modular and Cerberus PRO Modular panels. It is the mounting location and wiring termination point for the system option cards: field wiring lands on removable terminal blocks at the top, internal power at the bottom, and the cards talk to the rest of the panel over a common 60-pin data bus. It takes one module position on the backbox studs or on the optional CAB-MP mounting plate.
Key Features
- Two card slots; any option cards, no slot restrictions
- Occupies one position on the backbox studs or the CAB-MP mounting plate (CAB-1, CAB-2 or CAB-3 enclosures)
- Removable, numbered terminal blocks: field wiring on top (power limited), internal power on the bottom (non-power limited)
- 60-pin data bus connectors (P1, P2) plus a 6-pin CAN bus connector (P3); no active components on the card cage
- Molded card guides with card-position label; shipped with card guides removed
- Terminal blocks accept 12 AWG to 24 AWG wire
- UL 864 9th Edition and ULC certified; FM, CSFM and NYMEA approved
Specifications
| Model |
CC-2 |
| Card slots |
2 |
| Size |
4.78 in. W x 14.25 in. H |
| Mounting space |
1 module position (CAB-MP or backbox studs) |
| Data bus rating (P1/P2, fed from PSC-12) |
24 VDC, 2 A max; 6.2 VDC, 2 A max |
| Wire sizes |
12 AWG to 24 AWG |
| Installation instructions |
P/N 315-033035 |
Compatible With
- Siemens FireFinder XLS
- Siemens Desigo Fire Safety Modular
- Siemens Cerberus PRO Modular
- CAB-1 / CAB-2 / CAB-3 enclosures
- CAB-MP mounting plate
- PSC-12 / PSX-12 power supplies
