SDI AM100 is a Class 1 / Type 1 acoustic measurement instrument with STIPA speech intelligibility measurement. It is the successor to the SM90 with more storage, a better display and built-in wireless connectivity.
Features
- High-resolution capacitive touch TFT display
- 32 GB internal storage
- Wireless control over Bluetooth and WiFi
- Integrated signal generator for noise, STI signals, sines and sweeps
- Headset jack for monitoring and recording voice notes
- Rechargeable battery pack with USB charging
- Complies with IEC 60268-16 rev. 4, IEC 61672 Class 1, ANSI S1.4 Type 1, IEC 62160 Class 0 (RTA) and ISO 3382
- Includes microphone, charger, cables, windscreen and a rugged waterproof carrying case
Specifications
| Model |
AM100 |
| Class |
Class 1 / Type 1 |
| Display |
Capacitive touch TFT |
| Storage |
32 GB |
| Wireless |
Bluetooth and WiFi |
| Charging |
USB |
FAQ
What class of meter is the AM100?
SDi describes the Bedrock AM100 as its most advanced Class 1 / Type 1 acoustic measuring instrument.
How does it compare to the SM90?
It includes all the functionality of the Bedrock SM90 with higher specifications, such as more storage, a better display and integrated wireless connectivity.
What is it used for?
SDi lists it under speech intelligibility testing for emergency voice systems, alongside the Bedrock talkboxes and the SM50 meter.
