WATERFLOW DETECTOR, SCHEDULE 1040, 6
The Safe Signal WFD60N is a vane-type waterflow detector for 6 in steel sprinkler pipe, schedule 10 through 40. Water flow of 4 to 10 GPM or more deflects the vane and, after a field-adjustable mechanical time delay that filters out pressure surges and trapped air, operates two synchronized SPDT switches. It has a NEMA 4 enclosure for indoor or outdoor use and can be mounted on vertical (upflow) or horizontal pipe runs.
Key Features
- Vane-type waterflow detector for 6 in pipe (schedule 10 through 40 steel)
- Field-adjustable sealed mechanical time delay (retard) to reduce false alarms from surges
- Two sets of synchronized SPDT (Form C) contacts - e.g. alarm panel plus local bell or horn/strobe
- NEMA 4 enclosure, UL listed for indoor or outdoor use
- Visual and audible (73 dBA) switch activation
- Directional cover shows flow direction; tamper-resistant cover screws
- Field-replaceable timer/switch assembly (FS-RT)
- Wire-ready terminals accept up to 12 AWG
- Optional snap-in cover tamper switch (CTS)
- Vertical or horizontal mounting
Specifications
| Pipe size |
6 in |
| Compatible pipe |
Steel, schedule 10 through 40 |
| Hole size |
2 in |
| Static pressure rating |
450 psi |
| Triggering threshold (flow rate) |
4-10 GPM |
| Maximum surge |
18 ft/s |
| Contact ratings |
Two sets SPDT (Form C): 10.0 A, 1/2 HP @ 125/250 VAC; 2.5 A @ 6/12/24 VDC |
| Conduit entrances |
Two openings for 1/2 in conduit |
| Operating temperature |
32°F to 150°F (0°C to 66°C) |
| Enclosure rating |
NEMA 4 |
| Shipping weight |
5.6 lb |
| Service use |
NFPA 13, 13D, 13R, NFPA 72 |
| Warranty |
3 years |
Compatible With
- 6 in schedule 10-40 steel sprinkler pipe
- Fire alarm control panel initiating circuits
- CTS cover tamper switch kit
- FS-RT replacement delay mechanism and switch assembly
