CONN NM LCF1250 JL OS OR 6GHz CN price per piece
The RFS NM-LCF12-C02-6 is an OMNI FIT standard N male connector for 1/2" coaxial cable with an extended frequency range up to 6 GHz. The two-piece design fits both CELLFLEX copper and CELLFLEX Lite aluminum 1/2" cables, as well as the listed plenum, RADIAFLEX and DragonSkin 1/2" series, so one connector covers both outer-conductor materials. It is sealed with an O-ring to IP68 and has a typical third-order intermodulation of -159 dBc.
Key Features
- N male connector for 1/2" coaxial cable, OMNI FIT standard
- Extended frequency range: up to 6 GHz
- Two-piece design for field installation
- Compatible with copper and aluminum outer-conductor cable types
- 3rd-order IM product -159 dBc typical (@ 2 x 20 W)
- Waterproof to IP68 (O-ring sealing)
- RoHS (EU) and CRoHS (China) compliant
- Trimming tool: TRIM-SET-L12-C02
Specifications
| Connector interface |
N |
| Gender |
Male |
| Connector type |
OMNI FIT Standard |
| Cable size |
1/2" |
| Cable model series |
LCF12-50, ICA12-50, RCF12-50, RCA12-50, DragonSkin 2HB12-50 |
| Nominal impedance |
50 ohm |
| Maximum frequency |
6 GHz |
| 3rd order IM product @ 2 x 20 W |
-159 dBc typical |
| VSWR (return loss) |
1.03 (36.6 dB) up to 1.0 GHz; 1.04 (34.1 dB) 1.0-2.7 GHz; 1.08 (28.3 dB) 2.7-3.7 GHz; 1.08 (28 dB) 3.7-6.0 GHz |
| Sealing method |
O-ring |
| Waterproof level |
IP68 |
| Plating (outer/inner) |
Trimetal / Silver |
| Inner contact attachment |
Basket |
| Outer contact attachment |
Spring C-ring |
Compatible With
- RFS CELLFLEX LCF12-50 series 1/2" cable
- RFS ICA12-50 series
- RFS RCF12-50 series
- RFS RCA12-50 series
- RFS DragonSkin 2HB12-50 series
- RFS TRIM-SET-L12-C02 trimming tool
