Potter VM-1000 — addressable voice module and digital message repeater for the AFC-1000V integrated voice system.
In a Potter voice system the amplifiers live out in the building beside their speaker zones, and the VM-1000 feeds them. It sits on the panel P-Link as a supervised addressable device and drives two V-Link risers, so live paging, recorded messages and tones reach remote amplifiers over a riser pair instead of running speaker level audio back to the panel.
- Two V-Link audio riser outputs, Class A or Class B
- Connects to the panel P-Link over four conductors, Class A or B RS-485
- Auxiliary input accepts line level audio, 1 VRMS at 600 ohms, contact closure activated
- Microphone input, two Ethernet ports, SB-8 switch board connection
- P-Link current 53 mA standby, 69 mA alarm
- All circuits power limited and supervised
Buying caution: this is a P-Link module for a Potter voice panel, not a standalone amplifier. Confirm the host panel and its amplifiers before ordering.
