Potter PSN-1000 — UL certified 10 A intelligent notification power expander and P-Link repeater, Potter part number 3992662.
When a Potter addressable system runs out of notification power at the head end, this adds NAC capacity without a second panel. It hangs on the panel P-Link (RS-485) bus and is programmed and supervised by the panel, so settings and troubles land in panel history instead of behind dry contacts.
- Six Class B or three Class A outputs, each regulated, power limited, 3 A maximum
- Two programmable Class B supervised dry contact inputs
- Mounts up to 6,500 ft from the panel, then repeats P-Link a further 6,500 ft
- Quadrasync syncs AMSECO, Gentex, Cooper Wheelock and System Sensor strobes
- Charges 55 AH batteries, houses 18 AH; 120 or 240 VAC input; 32° to 120°F
Not a standalone supply — it must run from a compatible Potter panel (IPA, AFC/ARC, PFC-4064, legacy P and PFC-6000 series). For cabinet room for stacker modules such as PAD100-SLCE loop expanders, order the PSN-1000E.
Documents
FAQ
Can the PSN-1000 run on its own?
No. It connects to the control panel P-Link circuit and is programmed and supervised by a compatible Potter panel.
How far from the panel can it be installed?
P-Link wiring can run up to 6,500 ft, and the PSN-1000 repeats P-Link for a further run to additional P-Link devices such as LCD annunciators and SLC loop expanders.
What batteries does it support?
The battery circuit is rated for 8 to 55 Ah batteries, and the cabinet houses up to two 18 Ah batteries.
Does it have inputs?
Yes. Two dry-contact monitoring input circuits, I1 and I2, with ground fault detection.
